▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1150~1650MHz;
▷Gain(amplified):0dB ~ 21dB(Be specified);
▷Passive: -4.5dB (Be specified);
▷Pass DC from J1 to In Port, Block DC J2,J3,J4;
▷High Isolation: >30dB;
▷Low Noise Figure: <2.5dB
▷Avaible In TNC, SMA, BNC and N Connectors.
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 24dB(be specified);
▷Passive: -4.5dB (be specified);
▷Pass DC In & J1 and Block DC J2
▷High Isolation: >30dB;
▷Low Noise Figure: <2.5dB
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1150~1650MHz;
▷Gain(amplified):0dB ~ 24dB(be specified);
▷Passive: -4.5dB (be specified);
▷Pass DC In & J1 and Block DC J2
▷High Isolation: >28dB;
▷Low Noise Figure: <1.5dB
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1150~1650MHz;
▷Gain(amplified):0dB ~ 21dB(be specified);
▷Passive: -4.5dB (be specified);
▷Pass DC from J1 and J2 to In Port;
▷High Isolation: >28dB;
▷Low Noise Figure: <1.5dB
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 21dB(be specified);
▷Passive: -4.5dB (be specified);
▷Pass DC from J1 to In Port;
▷High Isolation: >28dB;
▷Low Noise Figure: <2.5dB
▷Design for wireless infrastructure applications;
▷Optional antenna current monitor and alarm;
▷Pole-mount environmental housing available(IEC 529 level IP55);
▷Surge protection available (Tested to EN61000-4-5)
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 21dB(Be specified);
▷Passive: -4.5dB (Be specified);
▷Pass DC from J1,J2,J3,J4 to In Port;
▷High Isolation: >28dB;
▷Low Noise Figure: <2.5dB
▷Avaible In TNC, SMA, BNC and N Connectors.
▷Full GNSS band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 21dB(Be specified);
▷Passive: -4.5dB (Be specified);
▷Pass DC from J1,J2,J3,J4 to In Port;
▷High Isolation: >28dB;
▷Low Noise Figure: <2.5dB
▷Avaible In TNC, SMA, BNC and N Connectors.
▷Full GNSS Band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 10dB(Be specified);
▷Pass DC from J1, to In Port(Standard);
▷Pass DC from J1~J8 to In Port(Optional);
▷DC Power Adaptor(Optional);
▷High Isolation: >30dB;
▷Low Noise Figure: <2.5dB
▷Avaible In TNC, SMA, BNC and N Connectors.
▷Programing Control the DC Pass or Block All Ports;
▷Monitoring The Voltage of All The Ports;
▷Connecting the PC Via The RS232 Port;
▷Design For R&D and Manufacture Test;
▷Full GNSS Band:GPS/GLONASS/Beidou/Galileo/IRNSS/QZSS/SBAS/NAVIC;
▷Frequency Range:1164~1616MHz;
▷Gain(amplified):0dB ~ 10dB(Be specified);
▷DC Power Adaptor(Standard);
▷High Isolation: >30dB;
▷Low Noise Figure: <2.5dB
▷Avaible In TNC, SMA, BNC and N Connectors.
